The GORDAK 857D is a high-performance, ESD-safe digital SMD rework station designed for precision electronics repair and professional rework applications. Equipped with a large LCD display, intelligent microcomputer PID temperature control, and a powerful 1000W heating system, it delivers rapid heating, stable temperature output, and exceptional ease of use. With advanced features such as 3 memory presets, password protection, auto-sleep sensing, soft-wind brushless fan technology, and self-diagnosis, the 857D offers outstanding efficiency, reliability, and user control in a compact workstation-friendly design.
-
Large LCD Digital Display – Clear and intuitive display for real-time temperature, airflow, and operating status.
-
Intelligent PID Closed-Loop Temperature Control – Microcomputer-controlled PID algorithm ensures precise, stable, and consistent temperature regulation. 1000W high-power heating element provides extremely fast heating and thermal recovery.
-
Brushless Fan with Soft-Wind Design – Low-pressure, gentle airflow ideal for blowing small SMD components without displacement or damage. PWM digital airflow regulation ensures smooth and accurate control.
-
3 Programmable Temperature Presets – Easily store and recall 3 customized temperature settings for fast workflow switching.
-
Auto Sleep Function with Handle Sensor – When the handle is placed on the holder, the machine automatically enters sleep mode, reducing energy consumption and extending service life.
-
Self-Diagnosis & Error Code Display – Built-in fault detection system displays error codes to simplify troubleshooting and maintenance.
-
Software Temperature Calibration – Simple software-based calibration function for correcting temperature deviations and ensuring long-term accuracy.
-
Lightweight, Ergonomic Handle – Comfortable design suitable for long working sessions and precise rework tasks.
-
Password Lock for Settings – Prevents unauthorized adjustment of temperature or airflow parameters.
-
Compact and Attractive Design – Small footprint saves workspace while offering a clean, professional appearance.
-
Long-Life Heating Element – Made with imported high-quality heating materials and advanced processing technology, providing significantly longer life than ordinary heating wires.
Specifications
| Item | Specification |
| Model | GORDAK 857D |
| Rated Voltage | 230 V AC, 50/60 Hz |
| Max Power | 1000 W |
| Pump Mode | Brushless Fan (Soft Airflow) |
| Air Flow | 120 L/min (Max) |
| Temperature Range | 100 – 500°C |
| Noise | < 45 dB |
| Ground Resistance | < 200 mΩ |
| Ground Potential | < 2 mV |
| Handle Length | Approx. 1.2 m (including nozzle) |
| Heating Element | Ceramic Heating Element |
| Packing | 8 pcs/ctn |
| Carton Size | 51 × 47.5 × 39 cm |
| G.W. | 19.5 kg |
