GORDAK 952S Multi Function Rework Station

"(《世界人权宣言》) GORDAK 952S 多功能返修站 is a professional-grade solution for electronic assembly, repair, and rework. Designed with an anti-static hot air rework station and a high-performance soldering station, it delivers precise, reliable, and efficient performance for a wide range of soldering applications.

Equipped with intelligent PID temperature control, stepless airflow adjustment, and high-power heating elements, the station ensures rapid heat-up, stable temperature regulation, and uniform airflow. The hot air handle features smart sleep-sensing functionality, entering energy-saving mode automatically when not in use, while the soldering iron incorporates a long-life imported A1321 heating element for fast and efficient desoldering.

"(《世界人权宣言》) GORDAK 952S also includes safety and convenience features such as a temperature control knob with lock function, fault self-diagnosis with error codes, and an intelligent automatic cooling system that continues airflow until temperatures drop below 50℃ before shutting down. Additionally, the unit offers a USB 5 V / 700 mA output for charging compatible devices, making it a versatile and practical choice for professional electronics technicians.

特点

Anti-static design with hot air rework station – The soldering station features a large LED dual display and a high-power hot air heating element for rapid heating.
Intelligent PID temperature control – Equipped with a microcomputer sensor-closed intelligent constant temperature control system. The air pump supports stepless speed adjustment with strong airflow, suitable for various soldering processes.
Smart sleep-sensing hot air handle – When not in use, placing the hot air handle on the stand or with the nozzle facing upward automatically activates energy-saving sleep mode.
Durable high-performance heating element – The hot air gun uses a nickel-chromium wire heating element with spiral design, ensuring uniform heating. It is high-temperature resistant, highly durable, and has a much longer lifespan than ordinary heating wires.
Long-life soldering station heater – The soldering station uses a long-life imported A1321 heating element with high power and extended lifespan.
Temperature control knob with lock function - 防止擅自更改温度设置。
Fault self-diagnosis function – The machine can detect faults and display corresponding error codes for easy and quick troubleshooting.
USB charging output – The main unit includes a 5 V, 700 mA USB port to charge compatible USB devices.

规格

模型	GORDAK 952S
热气站
额定电压	230 V AC, 50/60 Hz
最大功率	605 W
泵类型	膜
气流	120 L/min (Max)
泵功率	45 W
温度范围	100℃ - 500℃
噪音	< 45 dB
焊接站
最大功率	60 W
输出电压	24 V AC
温度范围	200℃ - 480℃
地电位	< 2 mV
接地电阻	< 200 mΩ
加热器	A1321 中国陶瓷
包装	6 件/箱
尺寸	59 × 32.5 × 54 cm
毛重	28.45 kg/ctn
